DataComm
Wilder Technologies is the first vendor to introduce the complete set of Compliance Test Fixtures for characterization measurements and conformance testing to the next generation 1.6 Tb/s Standards under development in IEEE 802.3dj, OIF CEI-224G, and Fibre Channel PI-9. The full offering includes Host Compliance Boards and Module Compliance Boards in both OSFP and QSFP-DD form factors, along with an ISI channel fixture offering a selection of differential loss traces for channel emulation and stressed receiver input stress calibration. The fixture set provides best in class performance beyond 60 GHz to support lane rates up to 58 GBaud PAM4 signaling used in 1.6T applications. CMIS_GUI Software provides: Displays of many of the settings and Controls in the Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well Scripts that directly access the CMIS Memory Map Registers.
ECOC'24 - OIF Booth #B83
DataComm
OSFP - 224G per lane
224G/1.6T PAM4 OSFP Wilder solution provides host configuration for Rx and Tx testing which conforms to IEEE 802.3dj specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Register.
Shop OSFP - 224G per laneDataComm
QSFP-DD 224G per lane
224G/1.6T PAM4 QSFP224 Wilder solution provides User-selectable host configuration for Rx, Tx,testing which conforms to IEEE 802.3dj specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Registers.
Shop QSFP-DD 224G per laneDataComm
DCOM-ISI-224G-12CH
Channel emulation and repeatable stressed input receiver testing for C2M (Chip to Module) and C2C (Chip to Chip) is even more important to assure interoperability at higher data rates. Wilder Technologies 224G (112 Gbaud PAM4) ISI channel board provides a selection of 12 loss channels to provide Inter-Symbol Interference for these testing applications. The selection includes the channel that when added to the loss of Wilder’s 1.6T OSFP and QSFP-DD Module Compliance Board fixtures conform to the requirements for the high loss module stressed receiver input test for the IEEE 802.3dj specification. Higher loss channels allow emulation of long C2C channels typical for DAC (Direct Attached Copper) passive cable applications. Features to enhance usability include the ability to mount the board vertical or horizontal in the frame for use with short interconnect cables, as well as adequate clearance around the RF Connectors to allow access for the torque wrench. The unique loss profile data for each fixture is included.
Shop DCOM-ISI-224G-12CHDataComm
DCOM-ISI-112G-9CH
Channel calibration and stress testing for C2M (Chip-to-Module) and C2C (Chip-to-Chip) high speed electrical interfaces is ever more important as we reach for higher data rates. Wilder Technologies 112G (56Gbaud) ISI – Intersymbol Interference loss modeling board provides 9-channel spread above and below the specification mean and is optimal for adding channel stress and signal calibration for IEEE 802.3ck channel testing. Whether calibrating your channel or stress testing your DUT, Wilder’s Datacom 112G ISI board will suit your needs. • Emulate channel loss for receiver testing • Controlled laminate and layout techniques • User adjustable position within frame • Access for proper application of torque to mated RF connectors • Unique and specific ISI profile provided with each board
Shop DCOM-ISI-112G-9CHDataComm
QSFP-DD - 112G per Lane
112G/800G PAM4 QSFP-DD Wilder solution provides User-selectable host configuration for Rx, Tx, Legacy, and DD testing which conforms to IEEE 802.3ck specifications. 56G/400G PAM4 QSFP-DD Wilder solution provides User-selectable host configuration for Rx, Tx, Legacy, and DD testing which conforms to IEEE 802.3cd specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Registers.
Shop QSFP-DD - 112G per LaneDataComm
OSFP - 112G per Lane
112G/800G PAM4 OSFP Wilder solution provides host configuration for Rx and Tx testing which conforms to IEEE 802.3ck specifications. 56G/400G PAM4 OSFP Wilder solution provides host configuration for Rx and Tx testing which conforms to IEEE 802.3cd specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Register.
Shop OSFP - 112G per LaneDataComm
SFP-DD
112G/200G PAM4 SFP-DD Wilder solution provides testing for host configuration which conforms to IEEE 802.3ck specifications. 56G/100G PAM4 SFP-DD Wilder solution provides testing for host configuration which conforms to IEEE 802.3cd specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Registers.
Shop SFP-DDDataComm
SFP112
112G/400G PAM4 SFP112 Wilder solution provides User-selectable host configuration for Rx, Tx,testing which conforms to IEEE 802.3ck specifications. 56G NRZ/112G PAM4 SFP112 Wilder solution also provides testing for host configuration which conforms to IEEE 802.3cd specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Registers.
Shop SFP112DataComm
QSFP112
112G/400G PAM4 QSFP112 Wilder solution provides User-selectable host configuration for Rx, Tx,testing which conforms to IEEE 802.3ck specifications. 56G NRZ/112G PAM4 QSFP112 Wilder solution also provides testing for host configuration which conforms to IEEE 802.3cd specifications. CMIS_GUI Software provides: Displays and Controls in Module including Lane States, Module Power States and Optical Power. Alarms and Warnings for Module Temp and Vcc and Optical Power Controls for Module Power, Margins, and read access to Descriptors and Data Path Configuration. Direct Read/Write access to the I2C and CMIS Memory Map as well as Scripts that directly access the CMIS Memory Map Registers.
Shop QSFP112DataComm
QSFP28/QSFP56
The QSFP28/QSFP56 Host Compliance Board (HCB) test fixture and our Module Complaince Board (MCB) test fixture supports 100Gbps using NRZ signaling or 200Gbps using PAM4 signaling.
Shop QSFP28/QSFP56DataComm
SFP28/SFP56
SFP28/SFP56 Host Compliance Board (HCB) test fixture and our Module Complaince Board (MCB) test fixture supports 100Gbps using NRZ signaling or 200Gbps using PAM4 signaling.
Shop SFP28/SFP56DataComm
QSFP+
The QSFP+ 40Gbps HCB and MCB test fixture kit will facilitate QSFP+ 40Gbps host and device compliance testing using our QSFP+ 40Gbps Host Compliance Board (HCB) test fixture and our Module Complaince Board (MCB) test fixture.
Shop QSFP+DataComm
SFP+
The SFP+ 40Gbps HCB and MCB test fixture kit will facilitate SFP+ 40Gbps host and device compliance testing using our SFP+ 40Gbps Host Compliance Board (HCB) test fixture and our Module Complaince Board (MCB) test fixture.
Shop SFP+DataComm
RJ-45 (CAT8)
The Ethernet IEEE 25GBASE-T/40GBASE-T RJ-45 (8P8C) TPA Plug Test Adapter (ETH-TPA-RJ45CAT8-P) exceeds testing hosts to the requirements of ANSI/TIA-568.2-D Category 8 and IEEE 802.3bt PoE++ standards. This next-generation cabling offers four times the bandwidth of standard Category 6A cabling and is fully backward compatible with Category 6A cabling, including RJ45 connectivity. Construction of the test adapter follows the EIA/TIA-568 standard with regard to pin/pair assignments and color coding, specifically incorporating the T568A configuration.
Shop RJ-45 (CAT8)DataComm
RJ-45 (CAT6)
The Ethernet 10G BaseT RJ-45 (8P8C) TPA Plug Test Adapter (ETH-TPA-RJ45) tests hosts to the requirements of the IEEE 802.3 specification. Construction of the test adapter follows the EIA/TIA-568 standard with regard to pin/pair assignments and color coding, specifically incorporating the T568A configuration.
Shop RJ-45 (CAT6)DataComm
EEE
The Energy Efficient Ethernet (EEE-TPA-ERK) test fixture Kit supports the 10BTe, 100BTe, and 1000BTe as specified in the IEEE 802.3az specification.
